DAB® 60212610 57C-ESYBOX-MINI
  1. pin-int

DAB® 60212610 57C-ESYBOX-MINI

DAB® 60212610 Booster Pump System, 0.25 gal Reservoir

  • Manufacturer: Dab Pumps Spa
  • Brand Name: DAB®
  • Part#: 57C-ESYBOX-MINI
  • MPN: 60212610
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at Vero Beach
  • loading Available at All Branches

Esybox Mini 3 has a different appearance than any other booster set and is small and completely integrated. Once you install and use it, you realize that the real difference is in the comfort and performance. Esybox Mini 3 uses the most advanced DAB technologies to create constant pressure according to the system demands and thus an optimization of energy consumption. Suitable for use with potable water, in domestic systems and gardening applications. The new 3-rotor model ensures further noise reduction and energy consumption. Managing the water pressure in your home has never been so simple and quiet. It is possible to create groups of maximum two pumps. It supports the remote control function thanks to the DConnect service integrated directly into the system.

DAB® Booster Pump System, Booster Pump, Electronic, 230 V, 4.8 A, 1.1 hp Horsepower Rating, 1 ph ph, 4.8 cu-m Flow Rate, Motor Duty Class: Class F, 750 kPa Working Pressure Rating, 0.25 gal Reservoir, 5 to 40 deg C, IPX4 Enclosure, 439 mm H x 263 mm W x 236 mm D, Additional Information: 50 Hz Frequency Rating

Additional Information      :      50 Hz Frequency Rating
Amperage Rating      :      4.8 A
Dimensions      :      439 mm H x 263 mm W x 236 mm D
Enclosure Type      :      IPX4
Flow Rate      :      4.8 cu-m
Horsepower Rating      :      1.1 hp
Motor Duty Class      :      Class F
Number of Phases      :      1 ph
Power Source      :      Electronic
Pump Type      :      Booster
Reservoir Capacity      :      0.25 gal
Temperature Rating      :      5 to 40 deg C
Voltage Rating      :      230 V
Working Pressure Rating      :      750 kPa
  • Self-priming multistage pump. Sound-absorbing protective enclosure. Technopolymer impellers. Stainless steel motor shaft. Non-return valve and pressure vessel are always built in.
  • Motor cooled by the liquid being pumped and encased in a stainless steel jacket. Complete with power cord with plug
  • Swivel display. Inverter for energy savings. Built-in safety features: protection against dry running, overload current, abnormal voltage, overheating and freezing, in addition to anti-seize and anti-cycling functions. Built to Italian standards CEI 2-3 and CEI 61-69 (EN 60335-2-41). Wizard for initial start-up, easy setup, and access to alarm log. Wireless connection.
