BERMAD S390-2W-24VAC-R SO-56A-S-390-2W-24AC-R
  1. pin-int

BERMAD S390-2W-24VAC-R SO-56A-S-390-2W-24AC-R

BERMAD S-390-2W Series S390-2W-24VAC-R Normally Closed Solenoid Actuator, 1/8 in Nominal, NPT x NPT, 2-Ways/Position

  • Manufacturer: Bermad CS Ltd
  • Brand Name: BERMAD
  • Part#: SO-56A-S-390-2W-24AC-R
  • MPN: S390-2W-24VAC-R
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at Vero Beach
  • loading Available at All Branches

The BERMAD S-390-2W is a compact two-way normally closed solenoid actuator, specially designed for reliable long life service in irrigation systems controlled by continuous current controllers. The BERMAD solenoid actuator is applicable directly to the valve cover or with a two-way base that enables combining the S-390-2W in variety of two-way control circuits. Model S-390-2W is compliant with all continuous current controllers on the market. It is excels in its low power and low sensitivity to dirt and voltage variations.

BERMAD Normally Closed Solenoid Actuator, S-390-2W Series, 1/8 in Nominal, NPT x NPT Connection, Number of Ways/Position: 2, 0 to 10 bar, 0.25 A Inrush, 0.125 A Holding, 24 V, 80 cm Cable Length, Nylon, Red, 80 deg C, 1-11/16 in H, Additional Information: 1.7 W Power, 1.8 mm Orifice, 0.32 sq-mm Cable, NBR Seal, Stainless Steel/Polyamide Wetted Part

Additional Information      :      1.7 W Power, 1.8 mm Orifice, 0.32 sq-mm Cable, NBR Seal, Stainless Steel/Polyamide Wetted Part
Amperage Rating      :      0.25 A Inrush, 0.125 A Holding
Cable Length      :      80 cm
Color      :      Red
Connection Type      :      NPT x NPT
Dimensions      :      1-11/16 in H
Material      :      Nylon
Nominal Size      :      1/8 in
Number of Ways/Position      :      2
Pressure Rating      :      0 to 10 bar
SPECIAL_ORDER_ITEM      :      Y
Series      :      S-390-2W Series
Special Order Item      :      Y
Temperature Rating      :      80 deg C
Voltage Rating      :      24 V
  • Proven pressure, voltage and weather-resistance
  • Highly durable in corrosive environments
  • High mechanical strength
  • Reliable operation under dirt loaded water
  • Low sensitivity to voltage variations
  • Low coil heating and sediment damage
  • Saves wires and infrastructures costs
  • Suites all continuous current controllers on the market
  • Simple installation, operation and maintenance
  • Reliable and durable product that bears the stamp of BERMAD quality
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/BERMAD_S390-2W-24VAC-R_Specification_Sheet.pdf
