Rain Bird® 200PESBR 76C-200PESBR
  1. pin-int

Rain Bird® 200PESBR 76C-200PESBR

Rain Bird® PESB-R Series 200PESBR In-Line Valve, 2 in Nominal, FPT x FPT, 0.25 to 200 gpm, 20 to 200 psi, 150 deg F

  • Manufacturer: Rain Bird
  • Brand Name: Rain Bird®
  • Part#: 76C-200PESBR
  • MPN: 200PESBR
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at Vero Beach
  • loading Available at All Branches

A true reclaimed water irrigation valve, able to handle chlorine and other chemicals found in reclaimed water systems. PESB-R Series valves offer long life and efficient, trouble-free performance even in harsh reclaimed water applications. Constructed of heavy-duty, glass filled nylon, these valves resist clogging and feature a patented scrubber to actively fight dirt, algae and other particles from blocking the pilot flow.

Rain Bird® In-Line Valve, PESB-R Series, 2 in Nominal, FPT x FPT Connection, 20 to 200 psi, 0.25 to 200 gpm Flow Rate, 150 deg F, 6-1/2 x 4 x 4 in

Connection Type      :      FPT x FPT
Dimensions      :      6-1/2 x 4 x 4 in
Flow Rate      :      0.25 to 200 gpm
Nominal Size      :      2 in
Pressure Rating      :      20 to 200 psi
Series      :      PESB-R Series
Special Order Item      :      N
Temperature Rating      :      150 deg F
  • 2 in chlorine-resistant valve for reclaimed water irrigation applications
  • Plastic diaphragm and scrubber components molded of chlorine and chemical-resistant plastic material
  • Durable glass filled nylon construction for long life and heavy-duty performance at 200 psi pressure
  • Stainless steel studs molded into the body
  • One-piece solenoid design with captured plunger and spring for easy servicing, prevents loss of parts during field service
  • External bleed protects the solenoid ports from debris when system is flushed
  • Internal bleed operates the valve without allowing water into the valve box and allows pressure regulator to be adjusted without turning on the valve at the controller first
  • Slow closing to prevent water hammer and subsequent system damage
  • Scrubber mechanism scrapes stainless steel screen clean to break down grit and plant material
  • Purple flow control handle standard
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Rain_Bird_SBCPLG_Catalog.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Rain_Bird_200PESBR_Specification_Sheet.pdf
  • linkVideo Link https://youtu.be/KfTM5mySU9w
