NETAFIM™ 70800-003260 SO-75C-61BBC-024
NETAFIM™ 70800-003260 Normally Closed Solenoid Valve With 24 V Coil, 1/2 in Nominal, Hub, 110 psi
- Manufacturer: Orbia
- Brand Name: NETAFIM™
- Part#: SO-75C-61BBC-024
- MPN: 70800-003260
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at Vero Beach
-
Available at All Branches
-
Price:
A solenoid valve receives an electric command from a controller and converts it into a hydraulic command to the main valve. This enables the opening and closing of the valve by allowing the passage of water into or from the control chamber of the main valve. Always use a normally closed (NC) solenoid on all PSNO valves. Standard solenoid is 24 VAC NC. All solenoids have a manual override feature. Turning the knob 90 deg to the left or right will activate the solenoid and place the valve in sustaining mode. Latching solenoids have a three position lever for manual override. Turning the lever to the right or "O" position activates the solenoid and places the valve in sustaining mode. Left or "C" position turns the valve off. For automatic mode, the lever should be placed in the center (locked) position.
NETAFIM™ Normally Closed Solenoid Valve With 24 V Coil, 1/2 in Nominal, Hub Connection, 110 psi, 24 V, 8 W, Brass Body 70800-003260
| Body Material | : | Brass |
| Connection Type | : | Hub |
| Nominal Size | : | 1/2 in |
| Power Rating | : | 8 W |
| Pressure Rating | : | 110 psi |
| SPECIAL_ORDER_ITEM | : | Y |
| Special Order Item | : | Y |
| Voltage Rating | : | 24 V |
Specification Sheet
