Liberty Pumps® 233 60A-L-233
Liberty Pumps® 230 Series 230 233 Submersible Sump Pump With Mercury-Free Float Switch, 115 V, 5.2 A, 1/3 hp
- Manufacturer: Liberty Pumps
- Brand Name: Liberty Pumps®
- Part#: 60A-L-233
- MPN: 233
- UPC: 671812002331
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at Vero Beach
Available at All Branches
-
Price:
Cool running and efficient, the 230 Series features a deep finned powder-coated aluminum motor housing, polypropylene base and vortex-style impeller. Topped-off with a quick disconnect power cord and Liberty's VMF switch (model 237) the 230 Series offers a superior value in a 1/3 hp pump.
Liberty Pumps® Submersible Sump Pump With Mercury-Free Float Switch, Model: 230, 115 V, 5.2 A, 60 Hz, 1/3 hp, 3450 rpm, 1-1/2 in Discharge, 10 ft Cord Length, Lubricated Bearing, 140 deg F, Thermoplastic Impeller, Aluminum/Polypropylene, 14 in Dia x 10-1/2 in H x 9-3/5 in W, Finish: Powder-Coated
| Amperage Rating | : | 5.2 A |
| Bearing Type | : | Lubricated |
| Cord Length | : | 10 ft |
| Dimensions | : | 14 in Dia x 10-1/2 in H x 9-3/5 in W |
| Discharge Size | : | 1-1/2 in |
| Finish | : | Powder-Coated |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/3 hp |
| Impeller Material | : | Thermoplastic |
| Insulation Material | : | Vinyl |
| Material | : | Aluminum/Polypropylene |
| Model | : | 230 |
| Package Type | : | Regular Pack |
| Series | : | 230 Series |
| Speed Rating | : | 3450 rpm |
| Temperature Rating | : | 140 deg F |
| Tongue Type | : | Ring |
| Voltage Rating | : | 115 V |
| Wire Size | : | 12 to 10 AWG |
- Vortex-style impeller permits passage of solids without clogging
- Stainless steel rotor shaft
- Non-corrosive stainless steel fasteners
- Oil filled, hermetically sealed motor with thermal overload protection
- Permanently lubricated upper and lower bearings
- Quick connect 10 ft standard power cord allows replacement of cord in seconds without breaking seals to motor (25 ft length optional)
- Lightweight, high performance submersible pump
- Vortex-style impeller made of high temp engineered thermoplastic
- Power-coated for corrosion resistance
- Anti-airlock hole allows trapped air to escape and the pump to prime and start pumping
- Removable base allows suction down to 1/8 in
