Irritrol® 102P1.5 72A-102-1.5
  1. pin-int

Irritrol® 102P1.5 72A-102-1.5

Irritrol® 100 Series 102P1.5 Anti-Contamination Control Valve, 1-1/2 in Nominal, 5 to 300 gpm, 10 to 100 psi

  • Manufacturer: The Toro Company
  • Brand Name: Irritrol®
  • Part#: 72A-102-1.5
  • MPN: 102P1.5
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at Vero Beach
  • loading Available at All Branches

The Irritrol® 100 Series (Century® PLUS) is an excellent example of a good valve getting better. Tracing its origin to the highly popular Century® Series, the 100 Series delivers reliable performance with a host of enhanced features. Offered in a globe/angle configuration with sizes ranging from 1 to 3 in, the 100 Series features a pressure range of 20 to 220 psi, optional modular pressure regulation, stainless steel metering, internal and external bleed, a nylon reinforced EPDM double beaded diaphragm and an anti-contamination design for dirty water applications (available on all 102 models).

Irritrol® Anti-Contamination Control Valve, 100 Series, 1-1/2 in Nominal, 10 to 100 psi, 5 to 300 gpm Flow Rate, 24 V, 7-1/2 in H x 5 in W x 4-3/4 in D, Additional Information: 0.48 A Inrush Current, 0.24 A Holding Current, EDPM Diaphragm

Additional Information      :      0.48 A Inrush Current, 0.24 A Holding Current, EDPM Diaphragm
Dimensions      :      7-1/2 in H x 5 in W x 4-3/4 in D
Flow Rate      :      5 to 300 gpm
Nominal Size      :      1-1/2 in
Pressure Rating      :      10 to 100 psi
Series      :      100 Series
Special Order Item      :      N
Voltage Rating      :      24 V
  • 150 mesh external control water filter and three-way solenoid provides non-continuous metering for recycled water applications
  • Tough, glass reinforced nylon, stainless steel and brass construction withstands high temperatures and system surges under pressure for long term reliability
  • Internal and external bleed (flush mode) allows for manual operation
  • 220 psi pressure rating, prevent water hammer and system damage in high pressure installations
  • Control water filter allows easy external service
  • Selectable normally open or normally closed mode (factory set at normally closed)
  • Accepts OmniReg® modular pressure regulator ensures consistent performance
  • Externally removable self-cleaning metering system ensure consistent performance in recycled water applications
